AMmk2 Series
IL-RSS-ORAM8.3mk2 Pro mini
Specifications * The specifications are subject to change
© Copyright 2024 INFiLED. INFiLED is a trademark of SHENZHEN INFiLED ELECTRONICS Co, LTD. The information contained herein is subject to change without notice. INFiLED shall not be liable for technical or editorial errors or omissions contained herein. For more information, please contact your local sales manager.
In / out Outdoor
Pixel pitch 8,33mm
Physical density 14.400 pixels/㎡
Led arrangement 3-in-1 SMD
Module dimensions 600x75mm (23,62x2,95inch)
Cabinet resolution (H/V) 144x72pixels
Cabinet dimensions 1200x600mm (47,24x23,62inch)
Cabinet weight 8,5kg (18,74lb)
Brightness 4000nits
Max power consumption (W/Panel) 330
Avg power consumption (W/Panel) 110
Viewing angle H/V) 160°/160°
Scan rate 1/28
Operating power source 100-240V AC 50/60Hz
Operating temperature -20℃~+50℃
Refresh rate 3.840Hz
Ip rating IP65
Transparency 70%
Signal input source DVI. HDMI. DP. SDI
Certifications CE.FCC.ETL. RoHS
