MV Edge Series

IL-FISS-ORMV7.8 Max mini

Infiled
Specifications * The specifications are subject to change

© Copyright 2024 INFiLED. INFiLED is a trademark of SHENZHEN INFiLED ELECTRONICS Co, LTD. The information contained herein is subject to change without notice. INFiLED shall not be liable for technical or editorial errors or omissions contained herein. For more information, please contact your local sales manager.

Add to compare
In / out Outdoor
Pixel pitch 7.8mm
Physical density 16,384pixel/m2
Led arrangement 3in1SMD
Module dimensions 500x250mm (19,69x9,84inch)
Cabinet resolution (H/V) 64x64pixels
Cabinet dimensions 500x500mm (19,69x19,69inch)
Cabinet weight 6,5kg (14,33lb)
Brightness 8000nits
Max power consumption (W/Panel) 160
Avg power consumption (W/Panel) 53
Viewing angle H/V) 160°/106°
Scan rate 1/4
Operating power source 100-240V AC, 50/60Hz
Operating temperature -10℃~+45℃
Refresh rate 3,840Hz
Ip rating IP65
Transparency 0%
Signal input source DVI,HDMI,DP,SDI
Certifications CE,FCC,ETL,ROHS,REACH,WEEE
