OREZ Series
IL-RSS-OREZ2.6 Plus
Specifications * The specifications are subject to change
© Copyright 2024 INFiLED. INFiLED is a trademark of SHENZHEN INFiLED ELECTRONICS Co, LTD. The information contained herein is subject to change without notice. INFiLED shall not be liable for technical or editorial errors or omissions contained herein. For more information, please contact your local sales manager.
In / out Outdoor
Pixel pitch 2,6mm
Physical density 147.456pixels/㎡
Led arrangement 3-in-1 SMD
Module dimensions 250x250mm (9,84x9,84inch)
Cabinet resolution (H/V) 192x192pixels
Cabinet dimensions 500x500mm (19,69x19,69inch)
Cabinet weight 7,6kg (16,76lb)
Brightness 4500nits
Max power consumption (W/Panel) 210
Avg power consumption (W/Panel) 70
Viewing angle H/V) 160°/160°
Scan rate 1/16
Operating power source 100-240V AC, 50/60Hz
Operating temperature -20℃~+50℃
Refresh rate 3840Hz
Ip rating IP65
Transparency 0%
Signal input source DVI. HDMI. DP. SDI
Certifications CE. CB. FCC. CCC. RoHS
